Series H CompactLine
The extremely compact H CompactLine soil compactors offer extremely high gradability of up to 60% and maximum ground clearance thanks to the drive provided by modern wheel motors. The three-point articulated swivel joint, combined with a very short wheelbase, ensure optimum driving and handling characteristics. The soil compactors in the H CompactLine are also very short, making them ideal for narrow construction sites and compaction work on rough terrain.
H 5i
| Weight | 11102 lbs |
| Drum width | 53.9 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 5i P
| Weight | 11367 lbs |
| Drum width | 53.9 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 7i
| Weight | 14421 lbs |
| Drum width | 66.1 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 7i P
| Weight | 14134 lbs |
| Drum width | 66.1 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 7i VIO
| Weight | 13947 lbs |
| Drum width | 66.1 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
Series H
H series soil compactors are the high-performance professionals for modern earthwork with a high compaction force. The compactors really showcase their qualities off-road – the three-point articulated swivel joint and the large slope angle front and back make them extremely maneuverable whilst ensuring optimum driving stability. Modern motors with future-proof technology ensure extremely low emissions.
H 10i
| Weight | 23990 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage IV/EPA Tier 4 |
H 10i P
| Weight | 26405 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage IV/EPA Tier 4 |
H 12i
| Weight | 25832 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage IV/EPA Tier 4 |
H 12i P
| Weight | 27254 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage IV/EPA Tier 4 |
H 13i
| Weight | 28356 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 13i P
| Weight | 30164 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 13i VIO
| Weight | 27805 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 13i C
| Weight | 29084 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 13i C P
| Weight | 30892 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 14i
| Weight | 30175 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 14i P
| Weight | 31984 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 16i
| Weight | 36228 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 16i P
| Weight | 37242 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 18i
| Weight | 40605 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 18i P
| Weight | 42082 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 20i
| Weight | 44332 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 20i P
| Weight | 45831 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 20i C
| Weight | 44618 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 20i C P
| Weight | 46096 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 25i
| Weight | 54960 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 25i C P
| Weight | 56150 lbs |
| Drum width | 84.3 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
H 25i VC
| Weight | 55698 lbs |
| Drum width | 87.4 in |
| Exhaust emissions category | EU Stage V / EPA Tier 4 |
All details, illustrations and texts are non-binding and may include optional additional fittings. Subject to technical modifications. Performance data dependant upon operational conditions.
