VF 600 Extending Screed
V
10 ft - 25 ft 5 in
10 ft
Extendable Screed for the Dash 5 Generation
The VF 600 with front-mounted extensions was developed specifically for the 10-foot highway-class pavers of the Dash 5 generation. Thanks to new screed geometry, it stands out for better visibility of all relevant paving areas, optimized material flow, and a particularly consistent material feed. This makes it ideal for paving requirements in the North American market – such as changing paving widths and high paving speeds.
Show less
Technical specifications
- Basic width
- Hydraulically adjustable
- Minimum paving width
- Maximum paving width
- Length
-
- Basic width
- 10 ft
- Hydraulically adjustable
- 10 ft to 19 ft 6 in
- Minimum paving width
- 10 ft
- Maximum paving width
- 25 ft 5 in
- Length
-
Extra bolt-on extensions 12 in 24 in
- Version
- Crown adjustment
- Height adjustment, extending units
- Slope, extending units (max.)
-
- Version
- hydraulic
- Crown adjustment
- -2 % to 5 %
- Height adjustment, extending units
- -1.2 in to 0.2 in
- Slope, extending units (max.)
- 10 %
- Compacting systems
- Vibrators (V)
- Version
-
- Compacting systems
- V
- Version
- eccentric vibrators
- Output generation
- Control
-
- Output generation
- three-phase AC generator
- Control
- electric, by heating rods
- Width (without end gate)
- Weight of basic screed
- Depth (in transport position)
-
- Width (without end gate)
- 10 ft
- Weight of basic screed
-
Screed Weight V 7,500 lbs
- Depth (in transport position)
-
Screed Depth VF 600 4 ft
