SW 218 TC

SW 218 TC

636

cu ft

18,519

lbs

3 - 42 kg/m²

Precise and powerful binding agent spreading

  • STREUMASTER binding agent spreaders are suitable both for spreading large quantities of binding agents during soil stabilization and for spreading small quantities of binding agents with maximum precision during cold recycling.
  • There are various different types and series of binding agent spreaders. Essentially, these can be subdivided according to type into the categories truck-mounted spreaders (M – Mounted) and towed spreaders (T – Towed). In addition to the vehicle type, these types also differ in the form of their spreading units: STREUMASTER primarily offers spreaders with cellular wheel spreading units (C - Cellular wheel).
  • The TC series binding agent spreaders are available as single-axle and tandem trailers and can be towed by towing vehicles with an engine output of either approx. 132 kW / 178 HP / 180 PS for single-axle or approx. 184 KW / 247 HP / 250 PS for tandem trailers.
  • With a maximum spreading width of 2,360 mm the TC and MC series achieve spreading rates of up to 60 kg/m² (at a speed of 2 km/h with a binder density of 1 kg/l).
  • In combination with products from the WIRTGEN GROUP, STREUMASTER binding agent spreaders cover the complete cycle in road construction and earthworks.
Show less
Highlights
Ideal Filling and Container Shape
Maximum Spreading Accuracy
Highly Efficient Material Conveying
Flexible Drive System
Innovative and Multifunctional Operating Concept
High-Precision WPT – WIRTGEN Performance Tracker

Technical specifications

Working width / Partial widths
Container capacity
Electrical system
Required driveshaft speed
Required engine power
Size of filling connector / filling hose
Empty weight
Spread rate at 2 km/h (DN 230-10 spreading unit)
Spread rate at 2 km/h (DN 230-20 spreading unit)
Spread rate at 2 km/h (DN 410-17 spreading unit)
Spreading quantity at 1.2 mph
Tongue load at towing gear
Permissible total weight
Working width / Partial widths
7 ft 9 in ( 2 ft 8 in / 2 ft 4 in / 2 ft 8 in)
Container capacity
636 cu ft
Electrical system
12 V / 60 A
Required driveshaft speed
1,000 rpm
Required engine power
>184 kW / 250 PS (all-wheel drive)
Size of filling connector / filling hose
4"
Empty weight
18,519 lbs
Spread rate at 2 km/h (DN 230-10 spreading unit)
3 - 42 kg/m²
Spread rate at 2 km/h (DN 230-20 spreading unit)
1 - 10 kg/m²
Spread rate at 2 km/h (DN 410-17 spreading unit)
5 - 60 kg/m²
Spreading quantity at 1.2 mph
1 - 60 kg/m²
Tongue load at towing gear
6,614 lbs
Permissible total weight
46,297 lbs

All details, illustrations and texts are non-binding and may include special equipment. We reserve the right to make technical changes without prior notice. Performance data are dependent upon actual operational conditions.
