HD+ 70i VV Tandem roller with two vibration drums
7,445 kg
1,500 mm
DEUTZ
Technical specifications
- Series
- Name
- Description
- Series
-
- Series
- HD+
- Name
- HD+ 70i VV
- Description
- Tandem roller with two vibration drums
- Series
- H302
- Operating weight with ROPS
- Empty weight without cab, without ROPS
- Operating weight with cab
- Static linear load, front
- Axle load, rear
- Axle load, front
- Max. operating weight
-
- Operating weight with ROPS
- 7,265 kg
- Empty weight without cab, without ROPS
- 6,550 kg
- Operating weight with cab
- 7,445 kg
- Static linear load, front
- 25.03 kg/cm
- Axle load, rear
- 3,690 kg
- Axle load, front
- 3,755 kg
- Max. operating weight
- 10,050 kg
- Total length
- Total width with cab
- Maximum working width
- Total height with cab
- Centre distance
- Ground clearance, centre
- Turning radius, inside
- Total height with ROPS
-
- Total length
- 4,480 mm
- Total width with cab
- 1,790 mm
- Maximum working width
- 1,635 mm
- Total height with cab
- 2,890 mm
- Centre distance
- 3,340 mm
- Ground clearance, centre
- 340 mm
- Turning radius, inside
- 4,230 mm
- Total height with ROPS
- 2,970 mm
- Drum type, front
- Drum type, rear
- Track offset, left
- Drum thickness, rear
- Drum thickness, front
- Drum diameter, rear
- Drum diameter, front
- Drum width, rear
- Drum width, front
-
- Drum type, front
- Smooth/non-split
- Drum type, rear
- Smooth/non-split
- Track offset, left
- 135 mm
- Drum thickness, rear
- 17 mm
- Drum thickness, front
- 17 mm
- Drum diameter, rear
- 1,140 mm
- Drum diameter, front
- 1,140 mm
- Drum width, rear
- 1,500 mm
- Drum width, front
- 1,500 mm
- Manufacturer
- Model
- Cylinders, quantity
- Power ISO 14396, rpm
- Power ISO 14396, HP
- Power ISO 14396, kW
- Power SAE J1349, rpm
- Power SAE J1349, HP
- Power SAE J1349, kW
- Exhaust emissions category, EU
- Exhaust emissions category, USA
- Exhaust emissions category, Korea
-
- Manufacturer
- DEUTZ
- Model
- TCD 2.9 L4
- Cylinders, quantity
- 4
- Power ISO 14396, rpm
- 2,300 rpm
- Power ISO 14396, HP
- 75.3 HP
- Power ISO 14396, kW
- 55.4 kW
- Power SAE J1349, rpm
- 2,300 rpm
- Power SAE J1349, HP
- 74.2 hp
- Power SAE J1349, kW
- 55.4 kW
- Exhaust emissions category, EU
- EU Stage 5
- Exhaust emissions category, USA
- EPA Tier 4
- Exhaust emissions category, Korea
- KOR Stage 5
- Regulation, infinitely variable
- Speed, infinitely variable
- Climbing ability, without vibration
-
- Regulation, infinitely variable
- HAMMTRONIC
- Speed, infinitely variable
- 0 - 9,7
- Climbing ability, without vibration
- 47 %
- Centrifugal force, rear, II
- Centrifugal force, rear, I
- Centrifugal force, front, II
- Centrifugal force, front, I
- Amplitude, front, II
- Amplitude, front, I
- Vibration frequency, rear, II
- Vibration frequency, rear, I
- Vibration frequency, front, II
- Vibration frequency, front, I
- Amplitude, rear, II
- Amplitude, rear, I
-
- Centrifugal force, rear, II
- 65 kN
- Centrifugal force, rear, I
- 80 kN
- Centrifugal force, front, II
- 65 kN
- Centrifugal force, front, I
- 80 kN
- Amplitude, front, II
- 0.35 mm
- Amplitude, front, I
- 0.6 mm
- Vibration frequency, rear, II
- 58 Hz
- Vibration frequency, rear, I
- 48 Hz
- Vibration frequency, front, II
- 58 Hz
- Vibration frequency, front, I
- 48 Hz
- Amplitude, rear, II
- 0.35 mm
- Amplitude, rear, I
- 0.6 mm
- Steering, type
-
- Steering, type
- Articulated steering
- Water sprinkling, type
-
- Water sprinkling, type
- Pressure
- Fuel tank, capacity
- Water tank, capacity
-
- Fuel tank, capacity
- 120 l
- Water tank, capacity
- 700 l
- Sound power level L(WA), guaranteed
-
- Sound power level L(WA), guaranteed
- 106
