VF 600 Extending screed
m
Extending screed with front-mounted extensions for 10-foot pavers
The VF 600 Extending Screed has been specially developed for the SUPER 2000-3i and SUPER 2003-3i pavers of the Highway Class, which feature high pave speeds and different pave widths. The screed‘s sturdy, smoothly sliding telescoping system guarantees precise paving in all pave widths. In addition, the screed is suitable for a wide range of paving profiles, including crowns and cross slopes.
Show less_US_Machine_View.JPG)
_US_Machine_View.JPG)
_US_Machine_View.JPG)
_US_Machine_View.JPG)
_US_Machine_View.JPG)
Screed telescoping system
VÖGELE screeds are renowned worldwide throughout the industry for their high level of precision and ruggedness. The VF 500 and 600 were designed specifically for the North American market and above all, stand for speed. Both screeds consistently satisfy the requirement to be able to pave at high speed and extremely variable pave widths: the telescoping system, for example, facilitates especially smooth-running and accurate pave width adjustment.
Electric screed heating
VÖGELE has put its faith in electric screed heating for decades. This extensive experience, in combination with continuous further development, means that VÖGELE screeds are now brought to temperature quickly and evenly.
Manufacturing technology Screeds
VÖGELE screeds feature leading-edge technology made possible by state-of-the-art production processes. The first of these processes, the precision cutting to shape of extremely wear-resistant sheet steel, takes place on laser cutting stations. Robots which operate continuously to a consistently high standard ensure long-lasting, stable welds.
Technical specifications
- Basic width
- Hydraulically adjustable
- Minimum pave width
- Maximum pave width
- Bolt-on extensions
- Cut-off shoes
-
- Basic width
- 3.05 m
- Hydraulically adjustable
- 3.05 m to 5.95 m
- Minimum pave width
- 1.83 m
- Maximum pave width
- 7.75 m
- Bolt-on extensions
-
Length 30 cm 60 cm
- Cut-off shoes
- 4 x 30.5 cm
- Version
- Crown adjustment
- Slope, extending units (max.)
- Berm
-
- Version
- hydraulic
- Crown adjustment
- -2 % to 5 %
- Slope, extending units (max.)
- 10 %
- Berm
- 30 cm, 45 cm, 60 cm
- Compacting systems
- Vibrators (V)
- Version
- Frequency (max.)
-
- Compacting systems
- V
- Version
- eccentric vibrators
- Frequency (max.)
- 50 Hz
- Heating rods
- Output generation
- Control
-
- Heating rods
- on screed plates
- Output generation
- three-phase AC generator
- Control
- fully automatic, thermostat-controlled
- Width (without side plate)
- Basic screed weight
- Depth (in transport position)
-
- Width (without side plate)
- 3.2 m
- Basic screed weight
-
Screed Weight V 3,350 kg
- Depth (in transport position)
-
Screed Depth VF 600 1.21 m
All details, illustrations and texts are non-binding and may include special equipment. We reserve the right to make technical changes without prior notice. Performance data are dependent upon actual operational conditions.
